XC2EDGVH-5.08mm
Thaum siv lub davhlau ya nyob twg thaiv, qee qhov kev ua txhaum cai yuav tshwm sim, xws li kho tsis raug. Txhawm rau tiv thaiv qhov no, XC cov kws tshaj lij qhia cov hauv qab no:
1. Interchangeability Check
Kev txheeb xyuas qhov sib hloov pauv yog txheej txheem tshuaj ntsuam xyuas dynamic. Nws ua kom ntseeg tau tias cov ntsaws ruaj ruaj thiab lub qhov (sockets) ntawm tib lub koob tuaj yeem txuas rau ib leeg txhawm rau txheeb xyuas cov teeb meem, xws li qhov tsis raug ntawm qhov tsis raug ntawm cov insulators lossis kev sib cuag, cov khoom ploj, lossis kev sib dhos tsis raug. Cov teeb meem no tuaj yeem tiv thaiv kev sib raug zoo, qhov chaw, thiab kev kaw, lossis txawm tias ua rau muaj kev sib cais hauv kev sib hloov. Lwm qhov txiaj ntsig ntawm kev sib pauv hloov pauv yog tias nws tuaj yeem tshawb xyuas cov hlau ntau dhau uas tuaj yeem cuam tshuam kev ua haujlwm rwb thaiv tsev los ntawm kev sib txuas ntawm threaded lossis bayonet. Yog li ntawd, lub davhlau ya nyob twg thaiv siv nyob rau hauv daim ntawv thov tseem ceeb yuav tsum tau soj ntsuam 100% kom tsis txhob muaj kev puas tsuaj loj thiab puas tsuaj.
2. Torque Test
Qhov kev ntsuas torque yog ib txoj hauv kev zoo rau kev ntsuas qhov kev ntseeg tau ntawm cov khoom siv davhlau ya nyob twg. Raws li tau teev tseg hauv Teb Chaws Asmeskas cov qauv tub rog MIL-L-39012, cov qauv yuav tsum tau xaiv los ntawm txhua pawg rau kev ntsuas lub zog kom paub sai sai rau cov teeb meem uas yuav tshwm sim.
3. Kev xeem dhau ntawm cov kab hluav taws xob crimped
Thaum lub sij hawm sib dhos hluav taws xob, nws feem ntau pom tias qee cov xov hlau crimped tsis raug tso lossis tsis kaw tom qab kev ntxig, ua rau tsis muaj kev sib cuag. Kev tshuaj xyuas qhia tau hais tias burrs lossis av yuav muaj nyob rau ntawm cov xov ntawm qee qhov mounting qhov, ua rau jamming. Qhov no yog tshwj xeeb tshaj yog pom nyob rau hauv lub xeem ob peb mounting qhov ntawm ib tug connector uas twb tau assembled los ntawm tus neeg siv. Thaum pom qhov tsis xws luag, nws yog ib qho tsim nyog yuav tsum tshem tawm tag nrho cov xov hlau crimped los ntawm lwm lub qhov thiab hloov qhov txuas. Tsis tas li ntawd, kev sib txuam tsis zoo ntawm txoj kab uas hla ntawm txoj kab uas hla thiab txoj kab uas hla crimping, los yog qhov yuam kev nyob rau hauv cov txheej txheem crimping, kuj tuaj yeem ua rau xoob crimped kev sib txuas.
| UL/CUL Techical Hnub | |||
| Siv Pawg | B | C | D |
| Rated voltage (V) | 300 | . | 300 |
| Rated tam sim no (A) | 10 | . | 10 |
| Hlau Ntau Solid / Stranded (AWG) |
. | ||
| Nrog VOLTAGE | 1600V / min | ||
| IEC Techical Hnub | |||
| Qeb Overvoltage | Ⅲ | Ⅲ | Ⅱ |
| Chav Kawm Kev Tiv Thaiv | 3 | 2 | 2 |
| Rated voltage (V) | . | 320 | 630 |
| Rated tam sim no (A) | . | 15 | 15 |
| Impulse Nrog Voltagea (KV) | . | 4.0 | 4.0 |
| Tus neeg xyuas pib hla ntu Khoom / Flexible (mm³) |
. | ||
| Khoom siv | |||
| Lnsulation Khoom | Termoplastic | ||
| Khoom siv Contactor | Tooj alloy | ||
| Kev tiv thaiv txheej | Tin plated | ||
| Neeg kho tshuab | |||
| Pitch (mm) | 5.08 | ||
| Ncej (p) | 2*(2-24) | ||
| Stripping Ntev (mm) | . | ||
| Ntsia Hlau / Torque (Max) (NM) | . | ||
| Ua haujlwm kub (degree) | -40-+105 | ||
| Pin Dimensions | 4.0 | ||
| PCB qhov taub (mm) | 1.6 | ||
